RSC165

2-way 165 mm (6.5") component system

ETON RSC 165 2-way 165 mm (6.5") component system is the new TOP performer in its class: especially due to the newly developed, rib-stiffened aramid fiber fleece foam sandwich membrane. This new high-tech material is a proprietary ETON development and is particularly advantageous in terms of sound performance. The specially constructed cone is produced in several layers using a specially developed manufacturing process - particularly light and rigid and therefore ideal for use as a bass/midrange driver. The very flat die-cast aluminum basket in ETON's typical double strut design is particularly torsion-resistant. The large voice coil and the powerful ferrite magnet with polished pole and base plate drive the woofer powerfully. The set also includes two newly developed 25 mm aluminum-ceramic tweeters with coupling volume and RCFS technology, separated by an easy-to-install cable crossover with level adjustment (0/+2 dB). Our new high performance system made in Germany!

ET-RSC165
€499.00
In stock
Pay in installments with Klarna. Learn more
Free shipping & returns

Product features

Pfeil zum Beschreibungstext

165 mm (6.5") component system with new cone technology made of rib-stiffened aramid fiber fleece foam sandwich material.  Ideal for crisp, contoured and full bass. Warm vocal reproduction with a sensational body & audibility, the finest nuances are reproduced to the point. Die-cast aluminum basket, flat construction with strong ferrite magnet with large pole core bore for a powerful and dynamic sound reproduction. The tweeter range features a newly developed, 3-layer 25 mm (1") aluminum-ceramic dome tweeter with coupling volume and RCFS technology for absolute sound enhancement. The tweeters impress with their extremely accurate reproduction. The set includes easy-to-install and efficiency-optimized cable crossovers with level adjustment (0/+2dB) as well as mounting rings with swivel and swivel function and angled housing.

RSC 165
Tweeter
25 mm (1")
Bass / midrange
165 mm (6.5")
Impedance
4 Ω
Nominal power (RMS
70 W
Music power
120 W
Sound pressure level
87 dB
Outer diameter
165 mm
Installation depth
60 mm

Technical data

Nominal impedance
Zn
4
Ω
Total moving mass (incl. air mass)
MMD
19.5
g
DC resistance
Re
3.3
Ω
Effective piston area
SD
137
cm2
Voice coil inductance
Le
0.22
mH
Resonance frequency TSP
fr
55
Hz
Force factor
BLxl
5.7
Tm
Suspension compliance
CMS
0.42
mm/N
Mechanical Q
QMS
7.35
Xmax mechanical
+/-
9.2
mm
Electrical Q
QES
0.69
Equivalent air vol. of suspension
VAS
11.1
dm3
Total Q
QTS
0.63
Characteristic SPL 1W / 1 m
87
dB
Mechanical resistance
RMS
0.93
kg/s
Rated power
70/120
W
magnet material
Ferrit
voice coil diameter
32
mm
Overall diameter
165
mm
Cutout diameter
146
mm
Frame depth
6.5
mm
Installation depth
60
mm
Screw hole diameter
4.5
mm
Terminal
2.8/4.8
mm
Weight
1.13
kg
