POW160.2

2-way 165 mm (6.5") component system

POW 160.2 – - a success story: innovative design, numerous features that can be heard and seen. The revised, flow-optimized metal basket gives the system optimum rigidity and ventilation. With its double-layer fiberglass paper diaphragm and strong ferrite magnet, impulse fidelity and dynamic sound reproduction are possible. Paired with the 25mm fabric tweeters that draw silky smooth high frequency detail, this system is the perfect all-rounder. Thanks to the 3 Ohm impedance, a high efficiency is achieved - even on series radios!

Product features

- eine Erfolgsgeschichte: innovatives Design, zahlreiche Features, die sich hören und sehen lassen können. Der überarbeitete, strömungsoptimierte Metallkorb verleiht dem System optimale Steifigkeit und Belüftung. Mit seiner doppellagigen Glasfaser-Papiermembran und dem starken Ferritmagneten sind Impulstreue und dynamische Klangwiedergabe möglich. Gepaart mit den 25-mm-Gewebehochtönern, die seidenweiche Hochtondetails zeichnen, ist dieses System der perfekte Allrounder. Dank der 3 Ohm Impedanz wird ein hoher Wirkungsgrad erreicht - auch bei Serienradios!.

POW 160.2
Tweeter
25 mm (1")
Bass / midrange
165 mm (6.5")
Impedance
3 Ω
Nominal power (RMS
70 W
Music power
100 W
Sound pressure level
94 dB
Outer diameter
165 mm
Installation depth
65 mm

Technology

Technical data

Nominal impedance
Zn
3
Ω
Total moving mass (incl. air mass)
MMD
12.8
g
DC resistance
Re
2.5
Ω
Effective piston area
SD
137
cm2
Voice coil inductance
Le
0.32
mH
Resonance frequency TSP
fr
69
Hz
Force factor
BLxl
4.3
Tm
Suspension compliance
CMS
0.41
mm/N
Mechanical Q
QMS
4.39
Xmax mechanical
+/-
9.0
mm
Electrical Q
QES
0.67
Equivalent air vol. of suspension
VAS
11.0
dm3
Total Q
QTS
0.58
Characteristic SPL 1W / 1 m
94
dB
Mechanical resistance
RMS
1.38
kg/s
Rated power
70/100
W
magnet material
Ferrit
voice coil diameter
25
mm
Overall diameter
165
mm
Cutout diameter
142
mm
Frame depth
3.3
mm
Installation depth
65
mm
Screw hole diameter
4.6
mm
Terminal
2.8/4.8
mm
Weight
0.96
kg
