PA2

2-channel Class-D power amplifier

Smallest size meets maximum performance and features! State-of-the-art advanced Class-D power amplifier technology enables an efficiency never before seen in this class with the smallest size and maximum amplifier power. Not only is the performance impressive with up to 2 x 140 W RMS, the sound is also impressive: with an ultra low THD+N of 0.01% distortion, it is one of the best on the market! The full range of active filters, connections (high and low level) and gadgets make the PA 2 a real problem solver and all-rounder. Ideal for concealed installation in the vehicle. High-quality die-cast aluminum housing in gunmetal finish with removable connector plugs and variable mounting feet as well as integrated adjustment tool for easy handling. Engineered in Germany.

Other products from this series

ET-PA2

€179.00

Out of stock

Pay in installments with Klarna. Learn more

Free shipping & returns

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product features

2-channel Advanced Class-D amplifier with state-of-the-art amplifier technology and high-quality die-cast aluminum housing with removable cover. The integrated adjustment tool makes it easy to adjust the amplifier, even overhead or in tight spaces. Full performance in the smallest size with 2 x 85 W RMS at 4 Ω, 2 x 140 W RMS at 2 Ω, 1 x 285 W RMS 4 Ω bridged. Signal-to-noise ratio 88 dB, damping factor @ 4 Ω >40, ultra low THD+N 0.01% @ 10 W 1 kHz, high-pass active filter CH1/2: 25 - 250 Hz, low-pass active filter CH1/2: 25 - 250 Hz, auto-sense on function (SIG / DC), switchable audio input signal on CH1-4, gain 0. 45 V - 6 V, adjustable high-level input voltage 1 - 15 V | 15 - 40 V, adjustable high-level input resistance 10| 150 | 600 Ω, 4 x audio input (high & low level), variable mounting feet, detachable connection plugs for power and audio signal cables, smart dimensions (LxWxH) 110 x 85 x 45 mm.
