RSR80
80 mm (3") Mitteltöner
Die Erweiterung zum 3-Wege System bietet das RSR 80 Mittelton-Set. Die spezielle Sandwichmembran, bestehend aus einer dreilagigen, verwindungssteifen Carbon-Rohacell-Glasfaser Mischung, ermöglicht einen gleichbleibend tonalen Klangcharakter. Der kräftige Neodymmagnet mit seiner großen Kernbohrung und der optimierten Magnetfeldsymmetrie in Verbindung mit dem pulverbeschichteten Aluminiumdruckgusskorb ergeben einen Mitteltöner der Extraklasse. Die gut belüftete Konstruktion bietet einen pegelfesten und verzerrungsarmen, hohen Wirkungsgrad und ein warm klingendes, dynamisches Mitteltonerlebnis. Platzsparende Anschlussterminals und moderate Einbaumaße sprechen für sich.
Product features
80 mm (3 inch) Mitteltöner mit Carbon-Rohacell Sandwich Membrane, zur Erweiterung des RSR160 & CSR16 zum 3-Wege System. 4 Ohm Impedanz, 20 W Nennbelastbarkeit, 30 W Musikbelastbarkeit, 87 dB Kennschalldruck, pulverbeschichteter Aluminium-Druckgusskorb mit starkem Neodym-Magneten. Inkl. Abdeckgitter, Made in Germany.
Technology
NEODYM-MAGNET - a powerful magnet, full control and compact in size. Neodymium magnets are characterised by their high pulse fidelity and the optimal magnetic field symmetry.
ALUMINIUM DIE-CAST BASKET - Increased stability with a minimum of weight, powder-coated, corrosion-resistant basket with optimized heat dissipation and flow-optimised. Reduced resonance of the material for a maximum of precision.
OPTIMISED-HEAT-DISSIPATION - The T-joke design has been specially designed to absorb and effectively dissipate heat generated by the magnet system, through the large core bore and specially designed ventilation ducts. without creating any flow noise.
OPTIMISED-VENTILATION - The basket design has been specially developed to ensure better heat dissipation to the environment, in addition the basket design minimises / prevents the generation of noise.
OPTIMISED-MAGNETIC-FIELD-SYMMETRY - Many factors during the production of a speaker chassis subsequently result in the symmetry of the magnetic field. It is a combination of the pole plate, the actual magnet and the T-joke as well as their properties in size, magnetic strength and the precision – how they are put together. We have optimised this process and with the highest precision to achieve the best performance.
MADE IN GERMANY - We have been developing and testing loudspeakers for over 35 years. Our entire manufacturing and development know-how plays a central role in this. This loudspeaker was developed and manufactured in Germany and has been subjected to our strict quality control. A promise of quality in terms of performance and workmanship.
Technical data
