PFX10

100 mm (4") coaxial system

The new PFX coaxial systems impress with their tonal balance and crisp bass reproduction. The 2-way coaxial sound systems are particularly easy to install and can be used as a front system or as a rear system for “rear fill”. The bass/midrange drivers feature the typical ETON powder-coated metal basket in a torsion-resistant, flow-optimized double strut design with large ventilation openings. A powerful ferrite magnet provides power and dynamics. Thanks to 3 Ohm technology, the coaxial speakers are extremely efficient - even with a standard radio / head unit, without an additional amplifier. Top sound in the entry-level class, thanks to rib-reinforced paper-glass fiber mixture for a cone that packs a punch. The membrane, which is manufactured using a complex manufacturing process, is not only extremely torsion-resistant, it is also particularly light - the best prerequisites for an impressive sound performance with crisp bass, dynamic and melodious. In combination with the integrated 19 mm (3/4") fabric dome tweeters, a perfect unit is created for outstanding sound - silky smooth and with the necessary brilliance and fine dynamics. The open design of the tweeter's touch protection ensures maximum sound transmission - especially behind original grilles. Tuned for the long haul with the necessary fun factor, the ideal coaxial speakers for your car with the best price-performance ratio!

Product features

Pfeil zum Beschreibungstext

100 mm (4") Koaxial-Lautsprechersystem mit integriertem 19 mm (3/4") Gewebedom-Hochtöner mit durchlässigem Kunststoff-Berührschutz für maximalen Durchlass. Rippenversteifte Glasfaser-Papiermembran Technologie für besonders druckvolle und konturierte MidBass-Wiedergabe, dynamisch und auf den Punkt. Pulverbeschichteter Metallkorb im ETON-typischen Doppelstrebendesign mit zusätzlichen Belüftungsöffnungen und Versteifungen sowie ablengbare 4-Punkt Langlochaufnahme. Kräftiger Ferrit-Magnet mit 3 Ohm Impedanz Schwingspule – für maximalen Wirkungsgrad auch ohne zusätzlichen Verstärker. Nennbelastbarkeit: 50 W RMS, Musikbelastbarkeit 80 W, Impedanz 3 Ohm, Kennschalldruck 87 dB, Außendurchmesser 100–124 mm, Einbaudurchmesser 113 mm, Einbautiefe 45 mm. Mit intergriertem hochwertigem Hochton-Kondensator. Engineered in Germany.

PFX 10
Tweeter
19 mm (3/4")
midrange
100 mm (4")
Impedance
3 Ω
Nominal power (RMS
50 W
Music power
80 W
Sound pressure level
87 dB
Outer diameter
100–124 mm
Installation depth
45 mm

Technical data

Nominal impedance
Zn
3
Ω
Total moving mass (incl. air mass)
MMD
4.80
g
DC resistance
Re
2.6
Ω
Effective piston area
SD
50
cm2
Voice coil inductance
Le
0.11
mH
Resonance frequency TSP
fr
101
Hz
Force factor
BLxl
3.2
Tm
Suspension compliance
CMS
0.51
mm/N
Mechanical Q
QMS
2.73
Xmax mechanical
+/-
5.2
mm
Electrical Q
QES
0.80
Equivalent air vol. of suspension
VAS
1.8
dm3
Total Q
QTS
0.62
Characteristic SPL 1W / 1 m
87
dB
Mechanical resistance
RMS
1.13
kg/s
Rated power
50/80
W
magnet material
Ferrit
voice coil diameter
25
mm
Overall diameter
100–124
mm
Cutout diameter
91
mm
Frame depth
3.45
mm
Installation depth
45
mm
Screw hole diameter
5.0
mm
Terminal
2.8/4.8
mm
Weight
0.55
kg
